0928400654 / 1465ZS0059 Fuel Pressure Control Valve Regulator for Opel 1.7 CDTI

Common Rail Pressure Control Valve.
Pressure regulator.
1465ZS0059
replaces 0928400654
INFO:
The fuel pressure control valve comprises a fuel-cooled solenoid valve.
The valve opening is varied by its solenoid coil being pulse width modulated at a frequency of 1 KHz.
When the pressure control valve is not activated, its internal spring maintains a fuel pressure of about 100 Bar.
When the valve is activated, the force of the electromagnet aids the spring, reducing the opening of the valve and so increasing fuel pressure.
The fuel pressure control valve also acts as a mechanical pressure damper, smoothing the high frequency pressure pulses emanating from the radial piston pump when less than three pistons are activated.
This part is called by many names including:
MPROP / FCA / Injection Pressure Regulator / Fuel Pressure Regulator / Fuel Control Actuator / Measuring Unit / Fuel Measurement Solenoid Valve
0928400654 can be used in car models:
OPEL ASTRA G Estate (F35_) 1.7 CDTI 04.2003-07.2009 59 80 1686
OPEL ASTRA G Hatchback (F48_, F08_) 1.7 CDTI 04.2003-01.2005 59 80 1686
OPEL ASTRA G Saloon (F69_) 1.7 CDTI 04.2003-01.2005 59 80 1686
OPEL ASTRA H (L48) 1.7 CDTI 03.2004- 74 100 1686
OPEL ASTRA H (L48) 1.7 CDTI 03.2004- 59 80 1686
OPEL ASTRA H Estate (L35) 1.7 CDTI 08.2004- 59 80 1686
OPEL ASTRA H Estate (L35) 1.7 CDTI 08.2004- 74 101 1686
OPEL ASTRA H GTC (L08) 1.7 CDTI 03.2005- 59 80 1686
OPEL ASTRA H GTC (L08) 1.7 CDTi 03.2005- 74 101 1686
OPEL ASTRA H Van (L70) 1.7 CDTI 03.2004- 74 101 1686
Analogous, Fully interchangeable parts:
ISUZU 8-93186-571-0, 8931865710
OPEL 93186571, 093186571, 81087, 0819517, 819517
0 928 400 493, 0928400493, 0928400654, 0 928 400 654
FISPA 81.087
HOFFER 8029201
MEAT & DORIA 9201
SIDAT 81.087
Pressure regulator can be fitted to the below fuel pumps:
0445010039, 0445010076, 0986437317, 0445010086
OPEL 97327924, 93189905
ISUZU 8-97227-026-4, 8-97227-026-2, 8-97227-3
