0928400656 / 1465ZS0005 Fuel Pressure Control Valve Regulator

Common Rail Pressure Control Valve.
Pressure regulator.
1465ZS0005
Replaces 0928400656
INFO:
The fuel pressure control valve comprises a fuel-cooled solenoid valve.
The valve opening is varied by its solenoid coil being pulse width modulated at a frequency of 1 KHz.
When the pressure control valve is not activated, its internal spring maintains a fuel pressure of about 100 Bar.
When the valve is activated, the force of the electromagnet aids the spring, reducing the opening of the valve and so increasing fuel pressure.
The fuel pressure control valve also acts as a mechanical pressure damper, smoothing the high frequency pressure pulses emanating from the radial piston pump when less than three pistons are activated.
1465ZS0005 can be used in car models:
ALFA 159 (939) 2.4 JTDM 09.2005-11.2011 147 200 2387
ALFA 159 Sportwagon (939) 2.4 JTDM 03.2006-11.2011 147 200 2387
ALFA 159 (939) 2.4 JTDM 05.2007-11.2011 154 210 2387
ALFA 159 (939) 2.4 JTDM Q4 05.2007-11.2011 154 210 2387
ALFA 159 Sportwagon (939) 2.4 JTDM 05.2007-11.2011 154 210 2387
ALFA 159 Sportwagon (939) 2.4 JTDM Q4 05.2007-11.2011 154 210 2387
ALFA 166 (936) 2.4 JTD 07.2006-06.2007 132 180 2387
ALFA 166 (936) 2.4 JTD 07.2005-06.2007 136 185 2387
ALFA BRERA 2.4 JTDM 20V 01.2006- 147 200 2387
ALFA BRERA 2.4 JTDM 20V 05.2007- 154 210 2387
ALFA SPIDER (939) 2.4 JTDM 04.2007- 147 200 2387
ALFA SPIDER (939) 2.4 JTDM 03.2008- 154 210 2387
FIAT CROMA (194) 2.4 D Multijet 06.2005- 147 200 2387
FIAT DUCATO Box (250) 120 Multijet 2,3 D 07.2006- 88 120 2287
FIAT DUCATO Box (250) 120 Multijet 2,3 D 4×4 03.2010- 88 120 2287
FIAT DUCATO Box (250) 130 Multijet 2,3 D 01.2007- 96 131 2287
FIAT DUCATO Box (250) 130 Multijet 2,3 D 08.2006- 93 126 2287
FIAT DUCATO Bus (250) 120 Multijet 2,3 D 07.2006- 88 120 2287
FIAT DUCATO Bus (250) 130 Multijet 2,3 D 01.2007- 96 131 2287
FIAT DUCATO Platform/Chassis (250) 120 Multijet 2,3 D 03.2010- 88 120 2287
FIAT DUCATO Platform/Chassis (250) 120 Multijet 2,3 D 07.2006- 88 120 2287
FIAT DUCATO Platform/Chassis (250) 130 Multijet 2,3 D 01.2007- 96 131 2287
FIAT DUCATO Box (250) 160 Multijet 3,0 D 07.2006- 115 156 2999
FIAT DUCATO Box (250) 160 Multijet 3,0 D 07.2006- 116 158 2999
FIAT DUCATO Bus (250) 160 Multijet 3,0 D 10.2006- 115 156 2999
FIAT DUCATO Bus (250) 160 Multijet 3,0 D 07.2006- 116 158 2999
FIAT DUCATO Platform/Chassis (250) 160 Multijet 3,0 D 07.2006- 116 158 2999
FIAT DUCATO Platform/Chassis (250) 160 Multijet 3,0 D 07.2006- 115 156 2999
IVECO DAILY IV Box Body / Estate 29L10 V 05.2006- 70 95 2287
IVECO DAILY IV Box Body / Estate 29L12 V, 29L12 V/P 05.2006- 85 116 2287
IVECO DAILY IV Box Body / Estate 29L14 C, 29L14 C/P, 29L14 V 05.2006- 100 136 2287
IVECO DAILY IV Box Body / Estate 35C10, 35S10 05.2006- 70 95 2287
IVECO DAILY IV Box Body / Estate 35C11 V, 35S11 V 07.2007- 78 106 2287
IVECO DAILY IV Box Body / Estate 35C12 V, 35C12 V/P, 35S12 V 05.2006- 85 116 2287
IVECO DAILY IV Box Body / Estate 35C13 V, 35C13 V/P, 35S13 V 07.2007- 93 126 2287
IVECO DAILY IV Box Body / Estate 35S14 C, 35S14 C/P, 35S14 V 05.2006- 100 136 2287
IVECO DAILY IV Box Body / Estate 40C10 V 05.2006- 70 95 2287
IVECO DAILY IV Box Body / Estate 40C11 V 07.2007- 78 106 2287
IVECO DAILY IV Box Body / Estate 40C12 V, 40C14 V/P 05.2006- 85 116 2287
IVECO DAILY IV Box Body / Estate 40C13 V, 40C13 V/P 07.2007- 93 126 2287
IVECO DAILY IV Bus 35S14, 35S14 /P 05.2006- 100 136 2287
IVECO DAILY IV Dumptruck 35C10 K 05.2006- 70 95 2287
IVECO DAILY IV Dumptruck 35C11 K, 35C11 DK, 35S11 K, 35S11 D 07.2007- 78 106 2287
IVECO DAILY IV Dumptruck 35C12 05.2006- 85 116 2287
IVECO DAILY IV Dumptruck 35C13 K, 35C13 DK, 35S13 K, 35S13 D 07.2007- 93 126 2287
IVECO DAILY IV Dumptruck 35S14 K, 35S14 DK 07.2007- 100 136 2287
IVECO DAILY IV Platform/Chassis 29L10 05.2006- 70 95 2287
IVECO DAILY IV Platform/Chassis 29L12 05.2006- 85 116 2287
IVECO DAILY IV Platform/Chassis 29L14 05.2006- 100 136 2287
IVECO DAILY IV Platform/Chassis 35C10, 35S10 05.2006- 70 95 2287
IVECO DAILY IV Platform/Chassis 35C11, 35S11, 35S11 D, 35S11 07.2007- 78 106 2287
IVECO DAILY IV Platform/Chassis 35C12, 35S12 05.2006- 85 116 2287
IVECO DAILY IV Platform/Chassis 35C13, 35C13 /P, 35S13 D, 35 07.2007- 93 126 2287
IVECO DAILY IV Platform/Chassis 35C14, 35S14, 35S14 /P 05.2006- 100 136 2287
IVECO DAILY IV Platform/Chassis 40C10 05.2006- 70 95 2287
IVECO DAILY IV Platform/Chassis 40C11, 40C11 D 07.2007- 78 106 2287
IVECO DAILY IV Platform/Chassis 40C12 05.2006- 85 116 2287
IVECO DAILY IV Platform/Chassis 40C13, 40C13 /P 07.2007- 93 126 2287
LANCIA THESIS (841AX) 2.4 D Multijet 04.2006-07.2009 136 185 2387
SAAB 9-3 (YS3F) 1.9 TTiD 12.2007- 132 180 1910
SAAB 9-3 (YS3F) 1.9 TTiD 12.2007- 118 160 1910
SAAB 9-3 (YS3F) 1.9 TTiD 12.2007- 96 130 1910
SAAB 9-3 Convertible (YS3F) 1.9 TTiD 12.2007- 132 180 1910
SAAB 9-3 Convertible (YS3F) 1.9 TTiD 12.2007- 118 160 1910
SAAB 9-3 Estate 1.9 TTiD 12.2007- 96 130 1910
SAAB 9-3 Estate 1.9 TTiD 12.2007- 118 160 1910
SAAB 9-3 Estate 1.9 TTiD 12.2007- 132 180 1910
SAAB 9-3X 1.9 TTiD 02.2009- 132 180 1910
UAZ PATRIOT 2.3 D 06.2006- 85 116 2286
Analogous, Fully interchangeable parts:
ALFA ROMEO 71754573
FIAT 71754573
LANCIA 71754573
0928400656, 0 928 400 656
FISPA 81.079
HOFFER 8029190
MEAT & DORIA 9190
SIDAT 81.079
INTERMOTOR 89544
0928400656 can be used on fuel pumps:
0445010123, 0445010285, 0445010349, 0445010222
0445010166, 0445010308, 0445010309, 0445010350
0445010173, 0445010233, 0445010389, 0445010252
0445010385, 0445010300, 0445010301, 0986437073
FIAT 55198519, 55204429, 55207676, 55207200, 55212707, 5801439052
IVECO 504097332, 504245256, 504296671, 5801439067, 5801469103
OPEL 93191383
SAAB 93191383
