0928400681 / 1465ZS0068 Pressure Control Valve Regulator for PSA Renault

Common Rail Pressure Control Valve.
Pressure regulator.
1465ZS0068
replaces 0928400575, 0928400632, 0928400681, 0928400715, 1465ZS0084
INFO:
The fuel pressure control valve comprises a fuel-cooled solenoid valve.
The valve opening is varied by its solenoid coil being pulse width modulated at a frequency of 1 KHz.
When the pressure control valve is not activated, its internal spring maintains a fuel pressure of about 100 Bar.
When the valve is activated, the force of the electromagnet aids the spring, reducing the opening of the valve and so increasing fuel pressure.
The fuel pressure control valve also acts as a mechanical pressure damper, smoothing the high frequency pressure pulses emanating from the radial piston pump when less than three pistons are activated.
This part is called by many names including:
MPROP / FCA / Injection Pressure Regulator / Fuel Pressure Regulator / Fuel Control Actuator / Measuring Unit / Fuel Measurement Solenoid Valve
1465ZS0068 can be used in car models:
CITROEN XSARA PICASSO (N68) 1.6 HDi 05.2004- 80 109 1560
FORD FOCUS C-MAX 1.6 TDCi 10.2003-03.2007 80 109 1560
FORD FOCUS II (DA_) 1.6 TDCi 11.2004- 74 100 1560
FORD FOCUS II (DA_) 1.6 TDCi 11.2004- 80 109 1560
FORD FOCUS II Estate (DA_) 1.6 TDCi 11.2004- 74 100 1560
FORD FOCUS II Estate (DA_) 1.6 TDCi 11.2004- 80 109 1560
FORD FOCUS II Saloon (DA_) 1.6 TDCi 04.2005- 80 109 1560
MAZDA 3 (BK) 1.6 DI Turbo 06.2004-06.2009 80 109 1560
MAZDA 3 Saloon (BK) 1.6 DI Turbo 06.2004- 80 109 1560
PEUGEOT 206 Hatchback (2A/C) 1.6 HDi 110 05.2004- 80 109 1560
PEUGEOT 206 SW (2E/K) 1.6 HDi 110 05.2004- 80 109 1560
PEUGEOT 307 (3A/C) 1.6 HDi 110 02.2004- 80 109 1560
PEUGEOT 307 Break (3E) 1.6 HDi 110 02.2004- 80 109 1560
PEUGEOT 307 SW (3H) 1.6 HDI 110 02.2004- 80 109 1560
PEUGEOT 407 (6D_) 1.6 HDi 110 05.2004- 80 109 1560
PEUGEOT 407 SW (6E_) 1.6 HDi 110 05.2004- 80 109 1560
RENAULT ESPACE IV (JK0/1_) 2.2 dCi (JK07) 02.2006- 102 139 2188
RENAULT LAGUNA II (BG0/1_) 2.2 dCi 05.2005- 102 140 2188
RENAULT LAGUNA II Grandtour (KG0/1_) 2.2 dCi 05.2005- 102 140 2188
RENAULT VEL SATIS (BJ0_) 2.2 dCi 12.2004- 83 113 2188
RENAULT VEL SATIS (BJ0_) 2.2 dCi (BJ0E, BJ0F, BJ0G, BJ0H) 09.2004- 102 140 2188
RENAULT VEL SATIS (BJ0_) 2.2 dCi (BJ0H) 04.2004- 85 116 2188
RENAULT MASTER II Box (FD) 3.0 dCi 140 (HD0S, FD0S, HD1S) 10.2003- 100 136 2953
RENAULT MASTER II Bus (JD) 3.0 dCi 140 (JD0T) 10.2003- 100 136 2953
RENAULT MASTER II Platform/Chassis (ED/HD/UD) 3.0 dCi 140 10.2003- 100 136 2953
RENAULT MASCOTT Box Body / Estate 120.35 05.2004-10.2010 85 115 2953
RENAULT MASCOTT Box Body / Estate 120.55 05.2004-10.2010 85 115 2953
RENAULT MASCOTT Box Body / Estate 160.35 05.2004-10.2010 115 156 2953
RENAULT MASCOTT Box Body / Estate 160.55 05.2004-10.2010 115 156 2953
RENAULT MASCOTT Platform/Chassis 120.35 05.2004-12.2010 85 115 2953
RENAULT MASCOTT Platform/Chassis 120.55 05.2004-12.2010 85 115 2953
RENAULT MASCOTT Platform/Chassis 120.65 05.2004-12.2010 85 115 2953
RENAULT MASCOTT Platform/Chassis 160.35 05.2004-12.2010 115 156 2953
RENAULT MASCOTT Platform/Chassis 160.55 05.2004-12.2010 115 156 2953
RENAULT MASCOTT Platform/Chassis 160.65 05.2004-12.2010 115 156 2953
VOLVO S40 II (MS) 1.6 D 01.2005- 81 110 1560
VOLVO V50 (MW) 1.6 D 01.2005- 81 110 1560
Analogous, Fully interchangeable parts:
RENAULT TRUCKS 50 01 867 926, 5001867926
SUZUKI 1561067JG1, 1561067JG1000, 15610-67JG1-000
0928400575, 0928400632, 0928400681, 0928400715, 1465ZS0084
FISPA 81.082
HOFFER 8029193
MEAT & DORIA 9193
SIDAT 81.082
Pressure regulator can be used on fuel pumps:
0445010081, 0445010089, 0445010094, 0986437322
CITROEN 1920FZ, 96481471, 96492841, 96518443
FORD 1230996, 1313844, 3M5Q9-A543-AA, 3M5Q9-A543-AB
MAZDA Y601 13800A -9A, Y601-13-800A
NISSAN 16700-DB000
PEUGEOT 1920FZ, 96481471, 96492841, 96518443
RENAULT 7701058123, 8200211430, 8200246722, 8200461506, 8200586856, 8200613056
RENAULT TRUCKS 74 850 016 61BX, 7485001661BX
VOLVO 36000262, 8603491
