0928400714 / 1465ZS0083 Pressure Control Valve Regulator for Renault

Common Rail Fuel Pressure Control Valve.
1465ZS0083
REPLACES 0928400714, 0928400675
INFO:
The fuel pressure control valve comprises a fuel-cooled solenoid valve.
The valve opening is varied by its solenoid coil being pulse width modulated at a frequency of 1 KHz.
When the pressure control valve is not activated, its internal spring maintains a fuel pressure of about 100 Bar.
When the valve is activated, the force of the electromagnet aids the spring, reducing the opening of the valve and so increasing fuel pressure.
The fuel pressure control valve also acts as a mechanical pressure damper, smoothing the high frequency pressure pulses emanating from the radial piston pump when less than three pistons are activated.
This part is called by many names including:
MPROP / FCA / Injection Pressure Regulator / Fuel Pressure Regulator / Fuel Control Actuator / Measuring Unit / Fuel Measurement Solenoid Valve
1465ZS0083 can be used in car models:
RENAULT GRAND SC??NIC II (JM0/1_) 1.9 dCi (JM14) 05.2005- 96 131 1870
RENAULT GRAND SC??NIC II (JM0/1_) 1.9 dCi (JM15) 05.2005- 81 110 1870
RENAULT LAGUNA II (BG0/1_) 1.9 dCi 09.2005- 92 125 1870
RENAULT LAGUNA II (BG0/1_) 1.9 dCi (BG1A, BG1V) 05.2005- 96 130 1870
RENAULT LAGUNA II Grandtour (KG0/1_) 1.9 dCi 09.2005- 92 125 1870
RENAULT LAGUNA II Grandtour (KG0/1_) 1.9 dCi (KG12) 08.2005-09.2007 85 116 1870
RENAULT LAGUNA II Grandtour (KG0/1_) 1.9 dCi (KG1V) 05.2005- 96 130 1870
RENAULT MEGANE II (BM0/1_, CM0/1_) 1.9 dCi 05.2005- 96 131 1870
RENAULT MEGANE II (BM0/1_, CM0/1_) 1.9 dCi 05.2005- 81 110 1870
RENAULT MEGANE II Coup??-Cabriolet (EM0/1_) 1.9 dCi 05.2005- 81 110 1870
RENAULT MEGANE II Coup??-Cabriolet (EM0/1_) 1.9 dCi 05.2005- 96 131 1870
RENAULT MEGANE II Estate (KM0/1_) 1.9 dCi 05.2005- 81 110 1870
RENAULT MEGANE II Estate (KM0/1_) 1.9 dCi 05.2005- 96 131 1870
RENAULT MEGANE II Saloon (LM0/1_) 1.9 dCi 05.2005- 96 131 1870
RENAULT MEGANE II Saloon (LM0/1_) 1.9 dCi (LM14, LM1D) 05.2005- 81 110 1870
RENAULT SC??NIC II (JM0/1_) 1.9 dCi 06.2003- 92 125 1870
RENAULT SC??NIC II (JM0/1_) 1.9 dCi (JM14) 05.2005- 96 131 1870
RENAULT SC??NIC II (JM0/1_) 1.9 dCi (JM15) 05.2005- 81 110 1870
SUZUKI GRAND VITARA II (JT) 1.9 DDiS 10.2005- 95 129 1870
Analogous, Fully interchangeable parts:
RENAULT 77 01 068 143, 7701068143
SUZUKI
15610-67JG1-000, 1561067JG1000
0928400714, 0928400675
Pressure regulator can be used on Fuel Distributor Tubes:
0445010087, 0 445 010 087
RENAULT 82 00 186 534, 82 00 229 004, 82 00 342 594, 82 00 372 388, 82 00 659 766
SUZUKI 1510-67JG2-000
