12 Circuit fuse block Automotive Marine Boat Truck RV Trailer Camper Car Fuses Box with Heat Shrink Ring Connector Terminals Red LED Indicator

12 way fuse block 12v – 32v.Red LED indicator,when fuse is wrong or disconnected,the indicator will light up
Fuse box supports circuit breaker type fuses and regular fuses.Advanced Insulation heat shring tubing connectors,Heat activated adhesive seals the wire ends from the elements,2 spare fuses storage area,Single circuit 30A fuse max,12volt – 32volinput
Fuse box has 2 spare fuses storage area,Single circuit 30A fuse max,12volt – 32volinput,PBT base,mechanical strength,insulated,temperature and flame resistant.
The fuse block for automotive car truck marine boat camper travel trailer RV bus solar setup etc
The fuse box include:1*fuse block,regular fuses:5A*2,10A*2,15A*2,20A*2,25A*2,30A*2+20 Heat Shrink Ring Connectors +4 Stainless steel screws+electric named labels
Product Description
Features
Fuse block supports circuit breaker type fuses with extra height
Fuse box with advanced Insulation heat shring tubing connectors,Heat activated adhesive seals the wire ends from the elements,2 spare fuses storage area,Single circuit 30A fuse max,12volt – 32volinput
Fuse box specifications:
Main line
Evaluation of the terminal: M5 stud (100A 32V DC.max).
Wire size: #4-6 AWG
Single line
Evaluation of the terminal: M4 stud bolt (30A 32V DC.max).
Wire diameter: #12-16 AWG.
Material:
Base:PBT
Cap:PC
Terminal:Nickel plated copper
Screw:Stainless steel
Label:PP 60
Package Including:
1 x 6 circuits fuse block with ground
2 x 5A fuse
2 x 10A fuse
2 x 15A fuse
2 x labels
4 x screws
20x Heat Shrink tubing Connectors
