1462C00984 / 0928400756 / 32R65-07100 Pressure Control Valve Regulator

Common Rail Fuel Pressure Control Valve.
1462C00984
INFO:
The fuel pressure control valve comprises a fuel-cooled solenoid valve.
The valve opening is varied by its solenoid coil being pulse width modulated at a frequency of 1 KHz.
When the pressure control valve is not activated, its internal spring maintains a fuel pressure of about 100 Bar.
When the valve is activated, the force of the electromagnet aids the spring, reducing the opening of the valve and so increasing fuel pressure.
The fuel pressure control valve also acts as a mechanical pressure damper, smoothing the high frequency pressure pulses emanating from the radial piston pump when less than three pistons are activated.
This part is called by many names including:
MPROP / FCA / Injection Pressure Regulator / Fuel Pressure Regulator / Fuel Control Actuator / Measuring Unit / Fuel Measurement Solenoid Valve
1462C00984 can be used in car models:
CITROEN C5 III (RD_) 3.0 HDi 240 04.2009- 177 241 2992
CITROEN C5 III Break (TD_) 3.0 HDi 240 04.2009- 177 241 2992
CITROEN C6 (TD_) 3.0 HDi 04.2009- 177 241 2992
JAGUAR XF (J05, CC9) 3.0 D 03.2009- 177 241 2993
JAGUAR XF (J05, CC9) 3.0 D 03.2009- 155 211 2993
JAGUAR XF (J05, CC9) 3.0 D 03.2009- 202 275 2993
JAGUAR XF SPORTBRAKE (CC9) 3.0 D 09.2012- 177 241 2993
JAGUAR XF SPORTBRAKE (CC9) 3.0 D 09.2012- 202 275 2993
JAGUAR XJ (X35_, J12, J24) 3.0 D 10.2009- 202 275 2993
LANDROVER DISCOVERY IV (LA) 3.0 SDV6 4×4 11.2009- 188 256 2993
LANDROVER DISCOVERY IV (LA) 3.0 TD 4×4 05.2010- 155 211 2993
LANDROVER DISCOVERY IV (LA) 3.0 TD 4×4 09.2009- 180 245 2993
LANDROVER DISCOVERY IV (LA) 3.0 TD 4×4 09.2009- 200 272 2993
LANDROVER DISCOVERY IV (LA) 3.0 TD 4×4 07.2012- 183 249 2993
LANDROVER RANGE ROVER SPORT (LS) 3.0 TD 4×4 06.2011- 188 256 2993
LANDROVER RANGE ROVER SPORT (LS) 3.0 TD 4×4 09.2009- 180 245 2993
LANDROVER RANGE ROVER SPORT (LS) 3.0 TD 4×4 08.2012- 183 249 2993
LANDROVER RANGE ROVER SPORT (LS) 3.0 TD V6 4×4 05.2010- 155 211 2993
PEUGEOT 407 Coupe (6C_) 3.0 HDi 06.2009- 177 241 2992
Analogous, Fully interchangeable parts:
0 928 400 756, 0928400756
MITSUBISHI 32R65-07100, 32R6507100
Pressure regulator can be used on fuel pumps:
0445010603, 0445010608, 0445010614, 0445010628, 0445010629, 0445010662
CITROEN 1920.RG, 9678393480
FORD 9X2Q-9B395-BA, 9X2Q-9B395-CA, AH2Q-9B395-AA, AH2Q-9B395-AB, AH2Q-9B395-AC, AH2Q-9B395-AD
ISUZU 8-98087-986-2, 8980879862
PEUGEOT 1920.RG, 9678393480
ROVER LR013180, LR019605, LR023597, LR027564
