1465ZS0093 / 0928400739 / 504197201 Fuel Pressure Control Valve Regulator

Common Rail Pressure Control Valve.
Pressure regulator.
1465ZS0093
replaces 0928400739
INFO:
The fuel pressure control valve comprises a fuel-cooled solenoid valve.
The valve opening is varied by its solenoid coil being pulse width modulated at a frequency of 1 KHz.
When the pressure control valve is not activated, its internal spring maintains a fuel pressure of about 100 Bar.
When the valve is activated, the force of the electromagnet aids the spring, reducing the opening of the valve and so increasing fuel pressure.
The fuel pressure control valve also acts as a mechanical pressure damper, smoothing the high frequency pressure pulses emanating from the radial piston pump when less than three pistons are activated.
This part is called by many names including:
MPROP / FCA / Injection Pressure Regulator / Fuel Pressure Regulator / Fuel Control Actuator / Measuring Unit / Fuel Measurement Solenoid Valve
Analogous, Fully interchangeable parts:
ALFA ROMEO 42560782
0928400619
FIAT 42560782
FISPA 81.091
HOFFER 8029205
IVECO 42560782
IVECO 504197201
LANCIA 42560782
SIDAT 81.091
0928400739 can be used in car models:
FIAT DUCATO Box (250) 2006
FIAT DUCATO Bus (250) 2006
FIAT DUCATO Flatbed / Chassis (250) 2006
IVECO 35C14
IVECO 35C15 M.Y.2006
IVECO 35C15 M.Y.2009
IVECO 35C15H M.Y.2006
IVECO 35C18 M.Y.2006
IVECO 35C18 M.Y.2009
IVECO 35S15BUS MY2006
IVECO 35S15H M.Y.2006
IVECO 35S18 M.Y.2006
IVECO 35S18 M.Y.2009
IVECO 35S18BUS M.Y.2009
IVECO 35S18BUS MY2006
IVECO 35S18W M.Y.2006
IVECO 40C15 M.Y.2006
IVECO 40C15 M.Y.2009
IVECO 40C15BUS MY2006
IVECO 40C15H M.Y.2006
IVECO 40C18 M.Y.2006
IVECO 40C18 M.Y.2009
IVECO 40C18BUS MY2006
IVECO 50C14
IVECO 50C14BUS
IVECO 50C15 M.Y.2006
IVECO 50C15 M.Y.2009
IVECO 50C15BUS MY2006
IVECO 50C15H M.Y.2006
IVECO 50C18 M.Y.2006
IVECO 50C18 M.Y.2009
IVECO 50C18BUS MY2006
IVECO 55S15W M.Y.2009
IVECO 55S18W M.Y.2006
IVECO 65C14 EURO4
IVECO 65C15 M.Y.2006
IVECO 65C15 M.Y.2009
IVECO 65C15H M.Y.2006
IVECO 65C18 M.Y.2006
IVECO 65C18 M.Y.2009
IVECO 70C15 M.Y.2009
IVECO 70C15-E3 M.Y.2009
IVECO 70C18 M.Y.2009
IVECO MASSIF
Pressure regulator can be used on fuel pumps:
504095664, 0 445 010 046, 0445010046, 0445010046, 0445010163, 0 445 010 163, 0445010163
