15-Amp Fully-Automatic Smart Battery Charger Maintainer 12V/24V for AGM GEL Lead-Acid Batteries Motorcycle UTV ATV Boat Car Truck

Designed for ALL 12V/24V lead acid batteries (WET, MF, AGM, GEL)
Compatible With OEM Brands such as Yuasa, Honda, Polaris, Yamaha, Kawasaki, Can-Am, John Deere, Cub Cadet, and Many More
Activated Voltage 4.2V for 12V battery, 16.5V for 24V battery; Charging Current MODE in Normal Temperaure 12V/14.3V??0.2V; 24V/28.6V??0.2V, MODE in Cold Temperaure 12V/14.7V??0.2V; 24V/29.4V??0.2V;
Automatic LCD display for 6V or 12V; LCD display shows battery bar for charge level; If the charger is connected incorrectly and there is reverse polarity or a short circuit is detected, the wrong
4 Modes -Normal, Winter, Silent, Winter/Silent Combined; 6 Charging Stages – Soft Start, Bulk 1, Bulk 2, Absorption, Float, Maintain; Input AC cable is 6 feet; Output cable is 6 feet; Soldered clips
Smart Battery Charger Maintainer
Battery Charger Specifications
Input AC cable is 6 feet
Output cable is 6 feet
Soldered clips are 3 inches long
Charger Display Status
If the charger is connected incorrectly and there is reverse polarity or a short circuit is detected, the wrong connection indicator will start to flash, (3 on diagram) and the battery voltage indicator (7 on diagram) will display ??Err??.If the battery voltage indicator reads a voltage lower than 4.2V, the LCD will display ??LO,?? and the charger will not charge the battery. The battery charger considers anything lower than 4.2V to be a dead battery.
Battery Status Indicator
The LCD display shows the battery state of charge by the percentage on the battery bar (2 on diagram).The battery bar will flash as the battery is being charged.The battery bar will increase as the battery state of charge increases and will keep constant at 100% when it is fully charged.
Automatic detection of 12V or 24V
The charger will automatically select the correct charging voltage based on the battery voltage type.The 12V or 24V symbol (5 on diagram) will be displayed on the LCD screen depending on the battery type that is connected to the charger.
