2 Stroke Outboard Motor 4HP Outboard Motor 63CC Boat Motor Heavy Duty Outboard Motor Boat Engine Air Cooling System Standard CDI Ignition System

2 Stroke, 4HP – Using 2 Stroke Power, Air Cooling Technology To Improve The Reliability Of The Whole Machine.
Convenient Use – Easy Operation And Convenient Maintenance. Comparable Lubricating System For 2 Stroke Outboard Engine Maneuverable and safe twist grip throttle control.
High Performance – Travel Safer, More Reliable, More Corrosion Resistant, More Beautiful, More Energy Efficient and More Environmentally Friendly.Suitable for: Freshwater and saltwater.
Perfect Design – Environmental Protection: Clean and Pure Gasoline ,The machine itself is lightweight, it can use on boat weight of 100kg or less , load-bearing 4 people.
Ignition System – Standard CDI ignition system for easy starting and improved performance,Perfect match inflatable boats, fishing boats, sailboats, and small yachts.NOTE:We don’t have the MSO of the motor. There is no serial number and no declaration of origin. We only have CE cer.tifica.tion, there is no other cer.tifica.tion can be provided, thanks for your conprehension!
Idle speed: 3000rpm
Gear ratio: 2.08(27/13)
Propeller diameter: 18cm
Propeller options: 7-1/4*5-A inch
Running speed: 15–18km/h
Technical Data :
Engine type: Single cylinder
Stroke: 2 stroke
Cooling System : air-cooled
Engine model: 1E48F
Displacement : 63cc
Ignition system: CDI Mixing
ratio(Gasoline:oil) 25:1 Gasoline tank
capacity: 1.2L
Max. Power: 2.8kw
Start system: Recoil start(manual start)
Instructions On Refueling:
The gasoline is highly flammable and explosive:
1.Don’t smoke,when refueling,keep away from fire, flame and ignitions of other sources.
2.Shut off the engine of your outboard engine before refueling.
3.Use unleaded gasoline only. Use 2 stroke engine oil.
4.The mixing ratio of gasoline and oil is 25:1. Mix the gasoline and oil and shake well.
5.Don’t spill the gasoline.Use clean cloth wipe off the spilled gasoline.
6.When start the engine, keep at least 3 meters distance from the refueling point.
Notice:
For this 2 stroke outboard motor, you need to use gasoline and oil mixed fuel, the gasoline and oil mixing ratio is 25:1.
Please use 93# gasoline and 2 stroke engine oil.
NOTE:We don’t have the M.S.O of the motor. There is no serial number and no declaration of origin. We only have C.E cer.tifica.tion, there is no other cer.tifica.tion can be provided, thanks for your conprehension!
