393630 Water Pump Impeller Repair Kit Replacement for OMC Outboards 20 25 30 35 HP Boat Motor Engine Parts Sierra 18-3382 0393509 0393630

This Water Pump Impeller Rebuild/Repair Kit Meets or Exceeds the OEM Parts Quality of OMC Outboard Boat Motor Engine It Replaces.
Fits Outboard Engine 20HP-25HP-30HP-35HP Boat Parts OEM Number 0393630 Year 1980 to 2005. More Details Please see Description Below.
Package Include Neoprene Impeller 395289,Pump Cup 328751,Pump Housing 393632,Wear Plate, Water Pump Impeller Gasket 325537, Install Bolts, Key,Seal, “O”- Ring
Cross Reference OEM Parts Number 0393509 0390344 0391636. Compliable with Sierra 18-3382 18-3381 GML 12070 Mallory Marine 9-48205 9-48211 SEI 96-362-01K Evinrude Johnson OMC BRP 777803 OBR Red Rhino JE-393.
To ensure this impeller kit is suitable for your boat motor, please double check your boat motor engine model and year it is VERY IMPORTANT! You can tell us your boat engine model and serial number or horsepower if you are not sure this parts. We re pleasure to help you.
393630 Water Pump Impeller Repair Kit Replacement for OMC Outboards 20 25 30 35 HP Boat Motor Engine Parts SIERRA 18-3382
Cross Reference the OEM P/N 393630, 0777803, 0393509, 0390344, 0391636. Sierra 18-3382 18-3381 Mallory Marine 9-48211 9-48205 GLM 12070 OBR Red Rhino JE-393 SEI 96-362-01K

APPLICATION:
Fits for OMC Outboards 2 Stroke
20hp 1985 & Later
25hp 1985 & Later
25hp Commercial 1998-2001
30hp 1980-1982
30hp (2 Cyl) 1983 & Later
35hp 1980-1982
35hp (2 Cyl) 1983 & Later

PACKAGE INCLUDED:
1 X Neoprene Impeller OEM P/N #: 395289 ; 1 X Wear Plate OEM P/N #: 328755
1 X Pump Housing OEM P/N #: 393632 18-3367; 1 X Pump Cup OEM P/N #: 328751
1 X Impeller Plate Gasket OEM P/N #: 325537;1 X Grommet OEM P/N #: 302497
1 X Impeller Key OEM P/N #: 330619 344470 777845 ; 1 X Rubber Seal OEM P/N #: 328753
1 X Brass Bushing OEM P/N #: 328754; 1 X O-Ring for Brushing 301877
1 X O-Ring 554545 ; 2 X O-Ring 311338;
6 X Stainless Steel Bolt with Washer 331979 324960 318452
