3Pack Waterproof Integrated Automobile Relay,5-PIN 12V DC 40/30 Amp SPDT Relay and Harness Set with Socket,Iron Back and 14 AWG Copper Wires for Boat Truck Motorcycle

Automotive Integrated Relay:3 pack consisting of three 5-pin relays and three wire harnesses,used for automotive circuit modification and car control device,easy to install
Excellent Material:The shell is made of flame retardant material,the inside is all copper coils and silver alloy contacts,which have better conductivity,stable and reliable work,durable.Thickened conductor wires greatly improve relay performance
Information for Harness: Heavy duty 14/16 AWG wiring harness.16AWG Pin85-Black,16AWG Pin86-White,14AWG Pin87-Red,14AWG Pin30-Yellow and 14AWG Pin87a-Blue.40/30 AMP high switching capability
Waterproof Design:Built-in sealing waterproof rubber ring,no matter in any bad weather,also can play a waterproof and moisture-proof effect
Scope of application:Widely used in cars, boats,motorcycles,fans,power switches,Led lights,battery breakers,fog lights,oil pumb control
Features:
Between Contacts and Coil:750VAC(for one minute)
Dielectric Strength:500VAC/M
Insulation Resistance:100M
Working Temperature: -40 C~+125 C
Operate/Release Time:10ms/10ms
Vibration Resistance:10-40Hz, 1.5mm
Installation Form:Quick Connect Type
Mechanical Life:1*10000000(at 300 Operations/minute)
Electrical Life: 1*100000(at 30 Operations/minute)

Waterproof 12V 40/30AMP Relay
3PACK 5PIN Relay and Harness Set
Waterproof:Yes
Contact Material:AgSno2
Normal Voltage:12VDC
Coil Power:1.8W
Humidity:40%-85%
Max Operating Voltage:30VDC
Max Switching Power: 560W
Max Operating Current:40A
Waterproof
The blue sealing rubber ring is tightly fitted,efficient waterproof and moisture-proof,it can be used in any harsh environment

Conductivity
All copper coils, silver alloy contacts and tinned copper wires with strong electrical conductivity, stable voltage and reliable operation

Flame Retardant
The hard shell is thick and smooth,not easy to deform and the flame-retardant material allows you to use it safely

High Temperature Resistance
The working temperature range is between -40 C and 125 C, which is heat-resistant and cold-resistant, preventing burnout or freezing,extended service life

Advantages:
Harness Set
This consists of 5 different colored lines
16AWG Pin85-Black 16AWG Pin86-White
14AWG Pin87-Red 14AWG Pin30-Yellow
14AWG Pin87a-Blue

Relay with 5PIN
Stable internal structure,usually more practical than 4pin relays.It can be generic even in more complex settings,widely used

Unique Interlocking Design
Special design makes installation more convenient,quickly connect the relay to the wiring harness for easier wiring,save time and energy
