6 Pin AC CDI BOX for GY6 50cc 125cc 150cc ATV Taotao Roketa Sunl Lance Scooter Moped Go Kart
6 Pin AC CDI BOX for GY6 50cc 125cc 150cc ATV Taotao Roketa Sunl Lance Scooter Moped Go Kart
6 Pin AC CDI BOX for GY6 50cc 125cc 150cc ATV Taotao Roketa Sunl Lance Scooter Moped Go Kart
6 Pin Round Connector/ Type: AC Fired CDI
Fit GY6 50cc 125cc 150cc ATV Taotao Roketa Sunl Lance Scooter Moped Go Kart 4 Wheeler Quad Bikes
NOT have a rev limiter, Easy to install, small enough to strap where its supposed to go
This is AC CDI, Which is smaller than the DC CDI While the appearance is just same only size different
Specifications
Type
AC Fired CDI
Pins
6 Pins Male Plug
Material Type
Plastic and Metal
Model
GY6 50cc 125cc 150cc ATV
Difference of AC CDI & DC CDI
AC CDI: The CDI Obtains it voltage solely form the current produced by the stator and is one of the most widely used basic in small enginesAC CDI : on the two plug part of the unit will always have 2 wire generally a black/red=stator power a white/black = engine killAC CDI ??scooter engine will run without a battery or on a dead battery
DC CDI: The DC CDI module is powered by the battery so an additional DC/AC inverter circuit is needed in the module to step up the voltage from 12VDC to a range 400-600VDCDC CDI: Is a lager unit due to the additional circuit and engine running with a DC-CDI set-up have a more precise timing and generally start better when the engine is cold.DC CDI: on most scooter is a 4 wire set-up but has been known a 5 wire set-up also, the sure way to know is to check its power source.
Mechanics Note on distinguishing AC fired or DC fired CDI box :
Wire and Plug
In the GY6 6-plug set-up, you have AC if you have 3-wires going into the 4-plug side and you have 2-wires going into the 2-plug side. On the other hand, you have DC if you have the larger CDI box, 3 or 4 wires going into the 4-plug side and only 1 wire going into the 2-plug side.
AC And DC Size
In general, the DC CDI’s tend to be larger in size than the AC ones.
Headlights
if the headlights turn on without the engine running, (with just the key on), it is a DC system. In the AC system the headlight requires the engine to be running. Another indication is, if the engine will only run with a battery it is DC. If it will run without a battery, it is a AC system.
