85MM MPH Speedometer Gauge 0-120MPH Boat GPS Speedometer Waterproof Marine GPS Gauge Speed Odometer for Car Truck Motorcycle with Red Backlight Replacement Speedometer 12V/24V

MPH Speedometer Gauge Install Diameter: ??85mm or 3-3/8″, Indication Range: 120MPH
Boat Speedometer Gauge IP67 waterproof and dustproof grade, Working Voltage: 9~32V DC
GPS Speedometer Shell USES PBT+ gf20%, melting point 220??, high temperature resistance, drug resistance, oil resistance.
100% imported MCU, stable performance. The acquisition frequency range is wide 0~10kHz.
Speedometer Gauge Able to receive arbitrary waveform signals (square wave, sine wave, triangle wave, sawtooth wave, etc.)
Product Description
Features:
1. 100% imported MCU, stable performance.
2. The acquisition frequency range is wide 0~10kHz.
3. Able to receive arbitrary waveform signals (square wave, sine wave, triangle wave, sawtooth wave, etc.)
4. Using high-precision stepping motor, pointer acceleration and deceleration curve movement can extend the life of the motor.
5. Using high-brightness LED as backlight, high brightness and long life.
6. The K value is adjustable, suitable for customers of different models.
7. The total accumulated mileage is adjustable, which is convenient for customers to reset after testing (this function is optional)
8. Accept customer’s requirements to customize.
Specification:
– Color: Black Silver
– Material: Stainless Steel 316L Bezel + Anti-fog Glass
– Install Diameter: ??85mm or 3-3/8″
– Signal: GPS
– Range: 0-120MPH
– Working Voltage: 9~32V DC
– Working Current: ??100mA
– Operating Temperature: -30?? ~ 75??
– Storage Temperature: -40?? ~ 85??
– Size: 12x8x12cm / 4.72×3.1×4.75 inch
Connection
1, Black: Ground(-)
2, Red: 9-30VDC
3, Yellow: Backlight
Package Included:
1 x GPS Speedometer
1 x GPS Antenna
1 x Instruction manual
