87-88107A5 Ignition Switch,Boat Push to Choke 2 Keys 6 Wire Base Ignition Key Starter Switch Assembly Replaces for Mercury 87-88107, 87-88107A5, 7-1155

The polyester shell is rust and corrosion resistant and ignition switch and key are made of high-quality plastic and metal materials, very durable and reliable, can ensure a long service life. Although it is not a real product, its design conforms to the original design. Equipped with hexagonal black plastic face nut and brass back cover nut, a 7/8 inch mounting hole is required on the panel.
Made of marine-grade glass-filled polyester construction is impact- and corrosion-resistant and fits a standard 7/8″dia. hole. Non-conductive housing eliminates potential shorts.
Hole Size: 7/8″;5/8″ maximum panel thickness, fits for side mount controls or panels up to 5/8″.
Replaces for Mercury part number: 87-88107 , 87-88107A5, 7-1155
Packing Include: 1 boat engine ignition switch | Direct replacement, can connect according to the color of the wire, very easy to install, plug into wiring harness.
Product Description
Description:
100% Brand New and High Quality
lgnition Key Switch with Push to Choke function
Switch with Potted Wire Base
3 Position: Off – Ignition – Start,includes 2 keys.
Fits for Side Mount Controls or Panels up to 5/8″
Rated Up to 30 amps 12V
Replaces for Mercury part number: 87-88107 , 87-88107A5, 7-1155
Use with Magneto Ignition.
Direct Replacement.
Fits Most Mercury Outboard Motors 1994 and Later using
Package includes:
1x Ignition Key Switch
2x Key
Wiring:
Red 12v
Black ground
Black/yellow for magneto
Yellow/black for choke
Yellow red for solenoid
Purple for ignition
Note:
Please check the pictures of this item and compare it with your part number carefully before you purchase!!!
Due to the different display and different light, the picture may not reflect the actual color of the item.
