90A Waterproof Brushless ESC Electronic Speed Controller with 5.5V/5A BEC and XT90 4.0mm Banana Head Connector for Model Ship RC Boat

FlyMonster-90A Use powerful & high performance MCU. Users can set functions as their demand, fully embody Intelligent characteristics. Unique circuit design, strong anti-interference.
Start mode can be set. throttle response fast, and it has a very smooth speed control linearity. Compatible with scale boat & racing boat .Low-voltage protection threshold value can be set.Built-in switch BEC, large power load with servo, lower power dissipation.
Waterproof design,Multiple protection functions: input voltage abnormal protection/ low-voltage cutoff protection, over-thermal protection and throttle signal loss protection, make the ESC more reliable.
High power safety performance: wherever the throttle lever is, the motor will not start immediately.Cycle menu setting, simple operation. Support setting with program box and transmitter.
Over thermal protection: when ESC temperature is over 100 ??C?? output power will automatically reduce. When it’s lower than 80??C output power will return to normal.
Product description
Waterproof design
Waterproof design(Note: if there is water in the ESC, Please dry the water at the connectors).
Multifunction Settings
Cyclical menu is easy to operate.Compatible with most of remote controllers and program cards.
Multiple protection functions
input voltage abnormal protection/ low-voltage cutoff protection, over-thermal protection and throttle signal loss protection, make the ESC more reliable.
50A
70A
90A
120A
150A
Battery
2-6s
2-6s
2-6s
2-6s
2-6s
Con. Current
50A
70A
90A
120A
150A
Burst Current(10S)
300A
420A
540A
720A
900A
BEC
5.5V/5A
5.5V/5A
5.5V/5A
5.5V/5A
5.5V/5A
Weight
90g
101g
102g
155g
169g
Size
57??49??18mm
57??49??18mm
57??49??18mm
76??56??25mm
76??56??25mm
Typical Applications
Boat length??55cm
Boat length??70cm
Boat length??100cm
Boat length??120cm
Boat length??135cm
