Dilwe RC Motor, 3380KV Sensorless Motor & 29S Water Cooling Jacket & 70A Brushless ESC for RC Boat RC Model Parts Accessories

Waterproof Design: This design extends ESC service life. If there is water in the ESC, please dry the water at the connectors.
Multiple Protection: low-voltage cut-off / over-heat protection / throttle signal loss protection / power reduction protection.
Application: This built-in 5.5V/3A BEC of ESC provides power for the receiver, and it can can be programmed.
Good Heat Dispersion: CNC machined 6061 T6 aluminum heatsink can behave good heat dispersion.
Fine Workmanship: precision and balanced rotor for best reliability and maximum RPM Black anodized finish for durability, corrosion resistance, and great looks.
Dilwe RC Motor, 3380KV Sensorless Motor & 29S Water Cooling Jacket & 70A Brushless ESC for RC Boat RC Model Parts Accessories
Motor Specification
Model
2958
Item Name
Brushless Motor
Material
Metal + Magnet
KV(RPM/Volt)
3380KV
RPM
60000
Watt
1400W
No Load Current
1.9A
Max Voltage
18V
Diameter
Approx. 29mm / 1.14inch
Length
Approx. 58mm / 2.28inch
Shaft Diameter
Approx. 3.175mm / 0.13inch
Fit
for 600-800mm RC Boat
Connector
4mm Golden Banana Connector

ESC Specification
Item Name
70A Brushless ESC with 5.5V/3A BEC
Cont. Current
70A
Burst Current
90A (10s)
Voltage
5-18 NC / 2-6 LiPo
Program
Yes
BEC
5.5V/3A
Item Size
Approx. 80 * 50 * 23mm / 3.15 * 1.97 * 0.91inch
Water Cooling Jacket Specifications
Item Name
29-S Water Cooling Jacket
Material
Aluminum
Color
Black
Designed for
2958 2948 RC Boat Brushless Motor
Outlet Fitting Diameter
Approx. 4.5mm / 0.18inch
Jacket Inner Diameter
Approx. 29mm / 1.14inch
Outer Diameter
Approx. 37mm / 1.46inch
Jacket Length
47mm / 1.85inch
Specification
Color
Shown As Pictures
Weight
356g
Type
RC Model Part & Acces
Package List
1 * Motor
Package List
1 * Water Cooling Jacket
Package List
1 * 70A Brushless ESC with 5.5V/3A BEC
Package List
2 * Water Cooling Tube
