DSE91255 24V 5A Battery Charger Diesel Generator Set Automatic Floating Charger Power Supply Equipment AC90-305V 50/60HZ

SMART CHARGING: It has a multi-stage smart charging function to maintain a constant current and constant voltage during the charging recovery phase. After charging is completed, it will automatically return to floating charging mode. Better protection of the charger, will not be damaged due to long-term use.
SUPERIOR PERFORMANCE: Provide reverse connection protection, short circuit protection and current limiting protection functions, high safety in use. It will not cause the battery to be overcharged or damage the battery beyond the rated voltage and current, and it is more safe to use.
EASY TO USE: You can use the on-board terminals to make a simple boost connection, which can promote and balance the battery power. It is a good power tool to improve battery performance and life. It is installed with EN 50022 35mm type guide rail, which is easy to operate and can be used with confidence.
ENERGY SAVING AND POWER SAVING: With a power saving mode, when the battery is fully charged, the charger will switch to Eco-Power to save energy. Not only does it save energy, but it also protects the battery better and prolongs the service life of the battery.
DURABLE: Made of ABS plastic, light weight, good flame retardancy, not easy to deform and break, and long use time. The components in the charger have been adjusted and the settings are accurate, please do not adjust at will.
Product Description
Specification:
Item Type: Battery Charger
Material: ABS plastic
Model: DSE9255 24V 5A
Input Rated Voltage (Standard Range): AC 110V-277V
Input Rated Voltage (Absolute Range): AC 90-305V
Input Voltage Frequency: 50/60HZ
Output Voltage: DC 24V
Output Rated Current: 5A
Working Temperature: -30??-55??
Rail Type: Only EN 50022 35mm type
Size: Approx. 140.4 x 136.5 x 63.4mm / 5.5 x 5.4 x 2.5in
Package List:
1 x Battery Charger
1 x User Manual
Note:
1. For personal safety, the grounding wire of this machine should be reliably grounded.
2. The charger is in a continuous working state, and there must be a certain space for heat dissipation and ventilation during use.
3. The components in the charger have been adjusted and set accurately, please do not adjust easily.
