Fuel Sender Unit Boat Fuel Tank Sending Unit Fuel Water Level Sensor Stainless Steel Fuel Sender and Fuel Gauge for Boat Car Truck RV (2″ (52mm))

[High Precision and Long Life]: The exterior is made of stainless steel, and the interior is controlled by high-quality reed switches. The sensor is corrosion-resistant, does not rust, has a long life, stable output signal, and accurate measurement. Suitable for gasoline, diesel, water, methanol, etc.
[Easy to Read]: The fuel level gauge has 8 adjustable backlight colors, IP67 waterproof, stainless steel frame, anti-fog curved glass, easy to read (Empty-1/2-Full).
[Easy Installation]: SAE 5 hole mounting pattern, NBR material gasket, good sealing performance, high oil resistance, with M5 5 screws, 10 quick wiring terminals, easy and quick installation by referring to the wiring diagram.
[Multi-Size]: Various sizes can be selected to meet different sizes of fuel tanks for Automobiles, Ships, Yachts, RV, Agricultural vehicles and Industrial equipment.
Note: To allow the sender not hit the bottom of the tank, the length of sender should be 1″ less than the depth of the tank if tank is plastic, and 0.5″ less than the depth of the tank if tank is metal .
Product Description
Specification of Fuel Sending Unit?? Material: Stainless Steel Length: 4″/6″/6.8″/8″/8.8″/10″/11″/12″/13″ Resolution Range: 10-21 mm Working Voltage: 9-32VDC Assembly: SAE standard 5 holes Mounting: 5pcs M5 screws and 2mm thick gasket Signal??240-33 ohms??240 ohms at empty, 33 ohms at full?? Operational Temperature: -40??F ~ +85??F (-40??C ~ +85??C) Specification of Fuel Level Gauge?? Material: Stainless Steel+ABS Fixing dimension: 52mm/2″ Indicating Range: E-1/2-F Signal:240-33 ohms Working Voltage: 9-32VDC(12V/24V) Backlight: Red /Green /Blue /Whit /Yellow /Yellow-green /Orange /Purple Operation mode: LCD display, stepper motor Protection Rank: IP67 Package Includes: 1x Fuel Sending Unit 1x NBR Gasket 5x M5 Screws 1x Fuel Level Gauge 1x Wiring Harness 10x Butt Terminals 1x Installation Instruction
