Golf Cart Brake Drum Hub Assembly for EZGO TXT PDS 1982-up Electric & 1982-1993 2-Cycle Gas, Replace OEM# 19186G1P

SKU ZDQ.05977 19186G1P Categories Disc Brake Systems, Golf Cart Parts Tag brake

SPREAD THE LOVE

Description

Golf Cart Brake Drum Hub Assembly for EZGO TXT 1982-up Electric Vehicles and 1982-1993 2-Cycle Gas Vehicles.
This brake drum/hub assembly replaces Part# 19186G1P.asy Installation & 1 year Warranty.
There is a 3/4-Inch center hole with a 24-tooth star spline The hub is held in place by a castellated nut (5/8-Inch x 18tpi) and a thick (118-Inch) flat washer.
This Brake hub/drum is a replacement for the earlier hub & drum and has the star spline instead of the straight key.And this is for the brake drum only. When replacing this brake drum, check the Hub assembly as well.
The drum is held in place by a castellated nut and a thick flat washer. This hub/drum will NOT operate with a keyed axle/hub interface.Warm tips: Hub spline and Rear Axle Shaft Spline should be matched tight. When one of them is wear out, both of them should be replaced at the same time. Other wise the hub spline will strip soon.
