Marine Boat 150HP Hydraulic Outboard Steering System Kit with Hydraulic Cylinder, Helm Pump and 26 Feet Hydraulic Steering Hose

Compatible with such brands as Yamaha, Suzuki, Honda, Mercury, Nissan, Tohatsu and more.
Universal design for outboards up to 150 horsepower.
Aluminum alloy casing and stainless steel ensure the wear resistance and corrosion resistance.
Replaceable parts with user-friendly design. Easy to install.
High strength reusable nylon hoses are equipped with quick-fit 1/4 pipe fitting.
Product Details and Features
Built-In Two-Way Lock
The cylinder is equipped with a build-in-two-way locking valve to eliminate the rebound torque during torsion.

Replaceable Shaft Seal
The shaft seal for pump can be replaced esaily for convinient purpose.

Quality Hose
The high-strength nylon hose with quick-fit 1/4″pipe fittings is easy to install and reusable.

Replaceable Sealing Rubber Ring
The sealing rubber ring for cylinder can be disassembled and replaced easily.

Easy To Install
The entire hydraulic steering system is designed for easy installation to provide you best experience.

Product Accessory Kit
All the accessories are made of high quality durable materials and they are coming with the package for free.

150HP HYDRAULIC STEERING KIT
For single-outboard powered boats rated up to 150 HP, including runabouts and inflatables .Compatible with such brands as Yamaha, Suzuki, Honda, Mercury, Nissan, Tohatsu and more.
Package Content
1 x Hydraulic Pump2 x Hose1 x Cylinder1 x Accessory Kit

Specifications
Pumps: NR150
Max Pression Bars: 6.9Mpa (1000psi)
Cylinders: MR150
Volume (cc): 116.9
Tube I.D (mm): 31.8
Rod I.D (mm): 16
Output Force (kgf):409.7
Strode (mm):197.3
