Mophorn Helm 1.4 Hydraulic Outboard Steering Pump HH4314-3

Premium Material: The HH4314-3 supersedes and replaces the HH4314, HH4514, and HH4016 helms,belongs to 150HP hydraulic outboard steering kit HK4200A-3. The hydraulic steering helm comes with high-strength aluminum alloy material, can effectively prevent seawater erosion.
Optimal Hose Fitting: The adjustable stainless steel O-ring fittings will simplify the installation process and allow for simple reorientation after installation. However, the NPT fittings cannot be used as they do not suitable for the pump.
Considerate Details: The hydraulic helm pump is equipped with the replaceable shaft seal, the built-in lock valve, relieve valve, and air pocket. These thoughtful details make it safe and convenient for you to use the equipment.
Complete Accessories: The hydraulic steering pump has a complete accessories kit for durable structure. It includes ball bearing piston race,-5 ORB ports, the ORB hose fittings 13lb, bleeder tubes, valves, and fixing bolts and screws kit.
Wide Application: This outboard helm pump is suitable for boats rated to a maximum of 150 HP. It can be used in mechanical/manual steering for yachts, bass boats, flats boats, fishing boats, and other waterborne vehicles.
Key Features
Sturdy Aluminum Alloy
Characterized by premium aluminum alloy structure, the boat steering pump features high-pressure resistance and corrosion resistance.

O-ring Type Fittings
The O-ring (ORB) fittings are made of stainless steel for easy hose routing and quick assembly. But do not use any NPT fitting or plug.

Replaceable Shaft Seal
The shaft seal protects fluid from leaking along the shaft. Besides, it can be easily replaced to extend the service life and facilitate easy operation.

Superior Built-in Details
The built-in lock valve is used for the positive rudder lock. The 1000 PSI relief valve helps adjust the pressure. The internal air pocket is able to eliminate the oil expansion overflow.

Standard Accessories
The hydraulic pump has a compact internal structure and fixing bolts and screws kit. Its standard accessories provide more comfortable steering for boats.

Extensive Use
This helm is ideal for cruisers, runabouts, center console boats, offshore fishing boats, and many more. It is also suitable for the boats that speed up to 60 MPH.

Specifications
Reference Number: HH4314-3Material: Aluminum AlloyWeight: 6.3 lb / 2.8 kgDimensions: 4.3 x 8 in. / 10.9 x 20.3 cm
Hydraulic Steering Helm
This hydraulic steering helm is made of aluminum alloy material with O-ring (ORB) fittings and considerate details to provide smoother and more comfortable steering for boats. It is ideal for cruisers, runabouts, center console boats, offshore fishing boats, and many more.
Note:
The HH4314-3 supersedes and replaces the HH4314, HH4514, and HH4016 BayStar helmsIf replacing the HH4016, new holes must be drilled as this utilizes four mounting studs and not three
Premium Material
Optimal Hose Fitting
Considerate Details
Complete Accessories
Hydraulic Steering Helm 2.0
Hydraulic Steering Helm 2.4
300HP Hydraulic Steering Helm
Part Number
HH5770-3
HH5272-3
HH5271-3
Powered Rated
Up to 350HP
Up to 350HP
Up to 300HP
Material
Aluminum Alloy
Aluminum Alloy
Aluminum Alloy
