TRM0060 Tilt Trim Motor for Yamaha 1995-2001 40/50 HP Short Shaft, Black and Silver
SKU DJ.00820 430-22048 Category Tag

TRM0060 Tilt Trim Motor for Yamaha 1995-2001 40/50 HP Short Shaft, Black and Silver

Specs: Tilt & Trim Motor, Voltage: 12, Rotation: RE, Dimension: Replacement Unit:, OD: 2.504in / 63.6mm, Shaft OD: 0.311in / 7.9mm, Shaft Length: 4mm, Length: 4.74in / 120.4mm, Shaft: 4mm X 8mm Drive Tang, Brief: Yamaha 40-50HP Outboard Motors 1995-01
Replaces OEM Numbers: API MARINE: PT611NM, ARCO MARINE: 6266, ARROWHEAD: TRM0060, EMP UnitS: 4-6789, J & N: 430-22048, LESTER: 10833, QUICKSILVER: 8M6007573, SIERRA MARINE: 18-6789, WAI: 10833N, Yamaha: 62X-43880-00-00, 62X-43880-01-00, 62X-43880-09-00
Compatible With/Replacement For: YAMAHA 40EJR 1995-1999, 40ELR 1995-1998, 40ESR 1995-1999, 40MJH 1995-1999, 40MJH 2000-2000, 40MLH 1995-1999, 40MLH 2000-2000, 40MSH 1995-1999, 40TLH 1996-1997, 40TLR 1995-1999, 40TLR 2000-2000, 50EJR 1995-1999, 50EJR 2000-2000, 50ELR 1995-1995, 50ELR 1997-1998, 50TLH 1995-1997, 50TLR 1996-1997, C40TLR 1997-1999, C40TLR 2000-2000, C40TLR 2001-2001, C50TLR 1998-2001, F40TLR 1999-1999, F50TLH 1996-1998, F50TLR 1996-1999, F50TLR 2000-2000
1-year warranty protects you after your purchase. We’re confident that our products will work flawlessly once installed in your vehicle. But in a rare case that it does not, we’ll replace it anytime within one year of your order. If you have a problem, we will take every step to assist you, contact us for a replacement.
100% New Aftermarket Tilt & Trim Motor built to meet OEM specifications
Product Description
Applications:
YAMAHA Marine TILT & TRIM All Models 40-100 H.P. 1995-2003
Specifications:
Voltage: 12 Volts
Rotation: Reversible
Field Hsg OD: 63.6mm / 2.504in
Overall Length: 120.4mm / 4.740in
Shaft OD: 7.9mm / 0.311in
Shaft Notes: 4mm X 8mm Drive Tang
Approximate Weight: 2.68 lbs / 1.22 kg
Notes: FOR YAMAHA 40-100HP 1995-2003
2-WIRE CONNECTION (RING TERMINAL ENDS)
3-BOLT MOUNT
Replaces these part numbers:
API MARINE PT611NM
ARCO MARINE 6266
LESTER 10833
MALLORY 9-18401
REMY SMALL MOTOR RT05042
YAMAHA 62X43880-00, 62X-43880-00, 62X43880-01, 62X-43880-01, 62X43880-09, 62X-43880-09
